DETAILS






CAMERA

  • Image Device: 1/3” CCD PC1089 Sensor

  • Viewing Angle: 120°

  • Signal System: PAL

  • Effective Pixels: 728 x 488

  • Sensing Area: 4.6228mm x 3.6112mm

  • Scanning System: 2:1 Interlace

  • Sync System: Internal

  • Horizontal Sync Frequency: 15.625 KHz

  • Vertical Sync Frequency: 50 Hz

  • S/N Radio: Better than 48dB

  • White Balance: Auto

  • Electronic Shutter: 1/50 (PAL) ~1/100,000 seconds

  • Operating Frequency: 2.4 ~ 2.4835 GHz

  • Receiving Sensitivity: -89 dBm

  • Line of Sight Range: 120 metres

  • Compression Format: MPEG4

  • Frame Rate: 25f/s

  • Transmit Output Power: 17 dBm

  • RF Bit Rate: 4Mbps

  • Minimum Illumination: 0 Lux (12 IR LEDs)

  • Night Vision Distance: 10m

  • Audio: Yes

  • Ingress Protection: IP69

  • Power Supply: DC 8-36V

INCLUDED

  • Mounting Brackets:

  • Dash Mount

  • U-Shape Mount

Accessories:

  • Sunshade

  • Remote Control

  • 3dB Patch Antenna forEnhanced Range
